Voltage Rating 30Vr.m.s. max.
Nominal Frequency Range DC to 6GHz
Nominal Impedance 50ohm
Temperature Rating -40oC to +85oC
Withstanding Voltage AC 200V ± 20V
Initial Contact Resistance
(without conductor resistance)
B> Voltage Standing Wave Ratio (V.S.W.R.) 1.9max. (DC  3GHz)
2 max. (3GHz ~ 6GHz)
B> Insertion Loss 1.3dB max. (DC ~ 3GHz)
2dB max. (3GHz ~ 6GHz)
B> Durability 2,000 cycles
