| Voltage Rating | 30Vr.m.s. max. |
| Nominal Frequency Range | DC to 6GHz |
| Nominal Impedance | 50Ω |
| Temperature Rating | -40°C to +85°C |
| Insulation Resistance | 500 MΩ min. |
| Withstanding Voltage | AC 200V ± 20V |
| Initial Contact Resistance (without conductor resistance) |
Center contact 70.0mΩmax. Outer contact 20.0mΩmax. |
| Voltage Standing Wave Ratio (V.S.W.R.) | 2.1 max. (DC ~ 3GHz) 2.1 max. (3GHz ~ 6GHz) |
| Insertion Loss | 1.9dB max. (DC ~ 3GHz) 3.1dB max. (3GHz ~6GHz) |
| Durability | 2K cycles |
